Dell P2018H - Bottom View

12 │ About your monitor
Bottom View
1
2
3
4 5
6
Bottom view without monitor stand
Label Description Use
1 Power port Connect the power cable.
2 HDMI port Connect your computer with HDMI cable (optional).
3 DP port Connect your computer to the monitor using a DP
cable.
4 VGA port Connect your computer with VGA cable.
5 USB connector (x2
downstream, x1
upstream)
Connect the USB cable that came with your
monitor to the computer. Once the cable is
connected, you can use the USB connectors on the
rear side and bottom side of the monitor.
6 Stand lock feature To lock the stand to the monitor using a M3 x 6mm
screw (screw not included).
