34 │ Operating your monitor
Using the front panel controls
Use the control buttons at the front of the monitor to adjust the settings on your
monitor.
1
52
3
4
The following table describes the front panel buttons:
Front Panel Button Description
1
Shortcut key/Preset
Modes
Use this button for choose from a list of
preset modes.
2
Shortcut key/Input
Source
Use the input source menu to select between
the different video signals that may be
connected to your monitor.
3
Menu
Use the menu button at launch your on-screen
display (OSD) and select the OSD menu. See
Accessing the Menu System.
4
Exit
Use this button to go back to the main menu
or exit the OSD main menu.
5
Power On/Off button
(with power-status light)
To turn the monitor on or off.
Solid white light indicates the monitor is
turned on and functioning normally.Blinking
white light indicates the monitor is in Standby
Mode.
