Setting up the monitor │ 29
Connecting the DP cable
Connecting the USB 3.0 cable
After you have completed connecting the DP/HDMI cable, follow the procedures
below to connect the USB 3.0 cable to the computer and complete your monitor
setup:
1.
Connect the upstream USB 3.0 port (cable supplied) to an appropriate USB 3.0
port on your computer. (See Bottom View for details.)
2.
Connect the USB 3.0 peripherals to the downstream USB 3.0 ports on the
monitor.
3.
Plug the power cables for your computer and monitor into a nearby outlet.
4.
Turn on the monitor and the computer.
If your monitor displays an image, installation is complete. If it does not display
an image, see Universal serial bus (USB) specific problems.
5.
Use the cable slot on the monitor stand to organize the cables.
