38 │ Operating your monitor
Auto Adjust Use this key to activate automatic setup and adjust
menu.
Brightness / Contrast
Dell 20 Monitor
Input Source
Color
Display
Others
Personalize
Menu
Auto Adjust
Press to adjust the screen automatically.
The following dialog appears on a black screen as the
monitor self-adjusts to the current input:
Auto Adjustment in Progress...
Auto adjustment allows the monitor to self-adjust to
the incoming video signal. After using auto adjustment,
you can further tune your monitor by using the pixel
clock (coarse) and phase (fine) controls under display
settings.
NOTE: Auto adjust does not occur if you press
the button while there are no active video
input signals or attached cables.
This option is only available when you are using the
analog (VGA) connector.
