Dell P2219H - Connecting HDMI and USB 3.0 Cables

34  │  Setting up the monitor
Connecting the HDMI cable (optional)
NOTE: The graphics are used for the purpose of illustration only.
Appearance of the computer may vary.
Connecting the USB 3.0 cable
After you have completed connecting the VGA/Disp
layPort/HDMI cable, follow the
procedures below to connect the USB 3.0 cable to the computer and complete
your monitor setup:
1. Connect the upstream USB 3.0 port (cable supplied) to an appropriate USB
3.0 port on your computer. (See Bottom view for details.)
2. Connec
t the USB 3.0 peripherals to the downstream USB 3.0 ports on the
monitor.
3. Pl
ug the power cables for your computer and monitor into a nearby outlet.
NOTE: Use the cable slot on the monitor stand to
organize the cables.
4. T
urn On the monitor and the computer.
If your monitor displays an image, installation is complete. If it does not display
an image
, see Universal Serial Bus (USB) specific problems.
