36 │ Setting up the monitor
To remove the stand:
1. Place the monitor on a soft cloth or cushion.
2. Pr
ess and hold the stand release button.
3. L
ift the stand up and away from the monitor.
VESA wall mounting (optional)
(Screw dimension: M4 x 10 mm).
Refer to the instructions that come wit
h the VESA-compatible wall mounting kit.
1. Pl
ace the monitor panel on a soft cloth or cushion on a stable flat table.
2. R
emove the stand. (See Removing the monitor stand)
3. Use
a Phillips crosshead screwdriver to remove the four screws securing the
plastic cover.
4. A
ttach the mounting bracket from the wall mounting kit to the monitor.
5. Mo
unt the monitor on the wall. For more information, see the documentation
that shipped with the wall mounting kit.
NOTE: For use only with with UL or CSA or GS-listed wall mount
bracket with minimum weight or load bearing capacity of 11.00 kg
(P2219H) / 12.44 kg (P2319H) / 13.04 kg (P2419H) / 17.40 kg (P2719H).
