Removing the display assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Follow the procedure from step 1 to step 6 in “Removing the base cover”.
2 Remove the battery.
3 Follow the step 1 procedure in “Removing the I/O board”.
4 Remove the wireless card.
Procedure
1 Remove the screw that secures the display-cable bracket to the system board.
2 Slide and lift the display-cable bracket off the system board.
54
