28 │ Setting up the monitor
Setting up the monitor
Attaching the stand
NOTE: The stand is not installed at the factory when shipped.
NOTE: The following instructions are applicable only for attaching the
stand that was shipped with your monitor. If you are attaching a stand
that you purchased from any other source, follow the setup
instructions that were included with the stand.
To attach the monitor stand:
1. F
ollow the instructions on the flaps of carton to remove the stand from the
cushion that secures it.
2. R
emove the stand base and stand riser from the packaging cushion.
NOTE: The graphics are used for the purpose of illustration only. The
appearance of the package cushion may vary.
3. I
nsert the stand base blocks fully into the stand slot.
4. L
ift the screw handle and turn the screw clockwise.
5. A
fter fully tightening the screw, fold the screw handle flat within the recess.
