Operating the monitor │ 65
Using the tilt, swivel, and vertical extension
NOTE: The following instructions are applicable only for attaching the
stand that was shipped with your monitor. If you are attaching a stand
that you purchased from any other source, follow the setup
instructions that were included with the stand.
Ti l t , swive l
With the stand attached to the monitor, you
can tilt and swivel the monitor for the
most comfortable viewing angle.
NOTE: The stand is not installed at the factory when shipped.
Vertical extension
NOTE: The stand extends vertically up to 150 mm. The figure below
illustrates how to extend the stand vertically.
