Setting Up the Monitor 35
Wall Mounting (Optional)
(Screw dimension: M4 x 10 mm).
Refer to the instructions that come with the VESA-compatible base
mounting kit.
1. Place the monitor panel on a soft cloth or cushion on a stable, flat
table.
2. Remove the stand.
3. Use a screwdriver to remove the four screws securing the plastic
cover.
4. Attach the mounting bracket from the wall-mounting kit to the LCD.
5. Mount the LCD on the wall by following the instructions that came
with the base-mounting kit.
NOTE: For use only with UL-listed wall-mount bracket with minimum
weight/load bearing capacity of 5.3 kg .
