Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
Display assembly Palm-rest assembly M2.5x6 Big Head 4
System board Palm-rest assembly M2x2 Big Head 4
Keyboard assembly Palm-rest assembly M1.2x1.4 20
Keyboard bracket Palm-rest assembly M2x2 Big Head 17
Sensor board Display-panel assembly
M2x2 Big Head
1
Touchpad Palm-rest assembly M2x2 Big Head 4
Before working inside your computer 11
