Removing the base cover
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Procedure
Procedure
1. Close the display and turn the computer over.
2. Remove the 12 screws (M2.5x8) that secure the base cover to the palm-rest assembly.
Figure 1. Removing the screws
a. screws (12)
b. base cover
3. Using your fingertips, pry the base cover off the palm-rest assembly.
3
Removing the base cover 13
