Dell P4317Q - Page 33

Operating your monitor | 33
Auto Adjust
Use this key to activate automatic setup and adjust menu.
Color
Display
PIP/PBP
Energy
Menu
Personalize
Others
Resolution: 1920x1080, 50Hz
Audio
Maximum: 1920x1080, 60Hz
Brightness / Contrast
Input Source
Press to adjust the screen automatically.
Auto Adjust
Dell P4317Q Energy Use
The following dialog appears on a black screen as the
monitor self-adjusts to the current input:
Auto Adjustment in Progress...
Auto adjustment allows the monitor to self-adjust to the
incoming video signal. After using auto adjustment, you can
further tune your monitor by using the pixel clock (coarse)
and phase (fine) controls under display settings.
NOTE: Auto adjust does not occur if you press the button
while there are no active video input signals or attached
cables.
This option is only available when you are using the analog
(VGA) connector.
