Replacing the power-button
module
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
Procedure
1 Align the screw hole on the power-button board with the screw hole on
the palm-rest assembly.
2 Adhere the tape on the power-button board.
3 Replace the screw that secures the power-button board to the palm-rest
assembly.
4 Slide the cable through the slot on the palm-rest assembly.
5 Turn the computer over and open the display.
6 Connect the power-button board cable to the system board.
Post-requisites
1 Follow the procedure from step 3 to step 8 in ”Replacing the computer
base".
2 Replace the keyboard.
3 Replace the wireless card.
4 Replace the hard drive.
5 Replace the base cover.
6 Replace the optical drive.
7 Replace the battery.
63
