Replacing the camera
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
Procedure
1 Using the alignment post, adhere the camera on the display back-cover.
2 Connect the camera cable to the camera connector.
Post-requisites
1 Replace the display bezel.
2 Replace the display assembly.
3 Follow the procedure from step 3 to step 8 in ”Replacing the computer
base".
4 Replace the keyboard.
5 Replace the wireless card.
6 Replace the hard drive.
7 Replace the base cover.
8 Replace the optical drive.
9 Replace the battery.
93
