Table 20. Dimension details
appliance Xa Xb Y Za (with
bezel)
Za (without
bezel)
Zb Zc
P570, P570F, V570,
V570F, and S570
482.0 mm
(18.98
inches)
434.0 mm
(17.09 inches)
86.8 mm
(3.42
inches)
35.84 mm
(1.41 inches)
22.0 mm
(0.87
inches)
678.8 mm
(26.72 inches)
715.5 mm
(28.17
inches)
Chassis weight
Table 21. Chassis weight
appliance Maximum weight (with all hard drives/SSDs)
VxRail P570, P570F, V570, and
V570F – 2.5 inch drive appliances
28.1 kg (61.95 lb)
VxRail S570 – 3.5 inch drive
appliances
33.1 kg (72.91 lb)
Processor specifications
Table 22. Processor specifications
appliance Maximum number of supported processors
VxRail V570 and V570F appliances Two Intel Xeon Processor Scalable Family processors
VxRail P570, P570F, and S570
appliances
Up to two Intel Xeon Processor Scalable Family processors
PSU specifications
The VxRail P570, P570F, V570, V570F, and S570 appliances supports two AC or DC redundant power supply units (PSUs).
Table 23. PSU specifications
Supported VxRail
configurations
PSU Class Heat dissipation
(maximum)
Frequency Voltage Current
VxRail P570, P570F,
V570, V570F, and S570
appliances
1100 W AC Platinum 4100 BTU/hr 50/60 Hz 100–240 V AC,
autoranging
12 A–
6.5 A
1100 W DC N/A 4416 BTU/hr N/A –(48–60) V DC,
autoranging
32 A
VxRail P570, P570F, V570,
and V570F appliances
1600 W AC Platinum 6000 BTU/hr 50/60 Hz 100–240 V AC,
autoranging
10 A
VxRail V570 and V570F
appliance
2000 W AC Platinum 7500 BTU/hr 50/60 Hz 100–240 V AC,
autoranging
11.5 A
NOTE: Heat dissipation is calculated by using the PSU wattage rating.
NOTE: This appliance is also designed to connect to the IT power systems with a phase to phase voltage not exceeding
240 V.
NOTE: If an appliance with 2000 W AC PSU operates at low line 100–120 V AC, then the power rating per PSU is derated
to 1000 W.
