Table 25. Memory specifications (continued)
DIMM
type
DIMM rank
DIMM
capacity
Single processor Dual processors
Minimum RAM Maximum RAM Minimum RAM Maximum RAM
RDIMM Dual rank 16 GB 96 GB 192 GB 192 GB 384 GB
RDIMM Dual rank 32 GB 192 GB 384 GB 384 GB 768 GB
Storage controller specifications
The VxRail P570, P570F, V570, V570F, and S570 appliances supports the following internal storage controller cards:
● HBA330
● Boot Optimized Server Storage (BOSS-S1)
Drives
The VxRail P570, P570F, V570, V570F, and S570 appliances supports NVMe, SAS, SATA, Nearline SAS drives, or SSDs.
Table 26. Supported drive options for the VxRail P570, P570F, V570, V570F, and S570 appliances
VxRail S570 appliance
configuration
14 drives appliance Up to 12 3.5 inch (Nearline SAS) front accessible drives in slots 0 to 11,
and up to two 3.5 inch (SAS) rear accessible drives in slots 12 to 13.
VxRail P570 and P570F
appliance configuration
24 drives appliance Up to 24 2.5 inch (NVMe, SAS, SATA or Nearline SAS) front
accessible drives in slots 0 to 23.
NOTE: VxRail P Series appliance supports NVMe drives in cache
tier, slots 20 to 23 only.
VxRail V570 and V570F
appliance configuration
24 drives appliance Up to 24 2.5 inch (SAS, SATA or Nearline SAS) front accessible drives
in slots 0 to 23.
Ports and connectors specifications
USB ports
The VxRail P570, P570F, V570, V570F, and S570 appliances supports:
● Two USB 2.0-compliant ports on the front of the appliance
● One internal USB 3.0-compliant port
● One micro USB 2.0-compliant port in the front of the appliance for iDRAC Direct
● Two USB 3.0-compliant ports on the back of the appliance
NIC ports
The VxRail P570, P570F, V570, V570F, and S570 appliances supports up to four Network Interface Controller (NIC) ports that
are integrated on the network daughter card (NDC), and are available in the following configurations:
● Four RJ-45 ports that support 100 M, 1 G, and 10 Gbps
● Four SFP+ ports that support up to 10 Gbps
NOTE:
You can install additional PCIe NIC cards. For more information on the PCIe NIC cards, see Expansion card
installation guidelines.
Technical specifications 25
