Table 40. Expansion card riser specifications (continued)
Supported
VxRail config
Riser config
and
supported
risers
Slot desc PCIe slots
on riser 1
(Height and
length)
Proc conn PCIe slots
on riser 2
(Height
and length)
Proc conn PCIe
slots on
riser 3
(Height
and
length)
Proc conn
Slot 3: x16
full-height,
half length
Processor 1 Slot 6: x8
low profile,
half length
Processor
1
Table 41. Riser configurations with 4 PCIe slots [Riser configuration 1 with or without rear storage
(1B+2B)]
Card Type Slot priority Maximum number of cards
Internal storage adapter Integrated slot 1
10 GB NIC 1, 2, 3 3
BOSS 4 1
Table 42. VxRail P series dual processor, and VxRail V570 and V570F configurations — Riser
configurations with greater than 4 PCIe slots [Riser configuration 4 (1A+2A+3A), and Riser configuration
5 (1B+2A+3A)]
Card Type Slot priority Maximum number of cards
GPU (double width) – Supported on
VxRail V570 and V570F appliance only
1, 8, 4 3
Internal storage adapter 6 1
10 GB NIC 4, 5, 7, 8 4
BOSS 3 1
NOTE: For information about slot form factor, see the Expansion card riser configurations table.
NOTE: The expansion card slots are not hot-swappable.
