Dell POWEREDGE 1900 - Installing the Bezel

Installing System Components 47
Figure 3-2. Installing and Removing the Bezel
Installing the Bezel
1 Insert the hooks on the end of the bezel into the bezel slots on the bottom of the system front panel.
See Figure 3-2.
2 Rotate the other end of the bezel toward the front panel and press the bezel onto the panel to engage
the latch.
3 Lock the bezel.
1 bezel latch 2 bezel 3 bezel slot (2)
4 bezel lock
1 23 4
