60 Installing System Components
Figure 3-10. Removing and Installing the Hard-Drive Bay
9 Remove the drive from the hard-drive bay. See Figure 3-11.
a Loosen the four screws that secure the hard drive in the hard-drive bay.
b Slide the hard drive out of the hard-drive bay.
1
2
4
3
1 screws (4) 2 drive bay 3 power cable
4 interface cable
