64 Installing System Components
Figure 3-13. Four-hard-drive Configuration (SAS Controller Card)
1 central fan retention bracket 2 expansion-slot 4 (PCIE_X4_4) 3 hard drive activity system
board connector
4 hard drive activity system
board connector
5 SAS1 connector 6 hard drive interface cable
connector
7 power cable connector
3
4
6
7
5
2
1
