86 Installing System Components
Figure 3-25. Removing the Control Panel Assembly
1 assembly cable guide bracket 2 chassis floor 3 control panel assembly
4 control panel assembly cable 5 mounting screws (2) 6 chassis-intrusion switch
5
3
2
1
4
6
