100 Jumpers and Connectors
Figure 6-3. PCIe Riser Card Connectors
Figure 6-4. PCI-X/PCIe Riser Card Connectors
1 slot 1, PCIe x4-lane (x8-lane
connector)
2 slot 2, PCIe x8-lane
1 slot 1, PCI-X 64-bit 133 MHz
(3.3 V)
2 slot 2, PCIe x8-lane 3 system management
1
2
3
2
1
