Front-Panel Features and Indicators
Figure 1-1
shows the controls, indicators, connectors, and features on the system front panel behind the
optional bezel. (To remove the bezel, press the latch at the left end of the bezel. See "Opening the
System
" on page 46
.)
Table 1-2 provides component descriptions.
Figure 1-1. Front-Panel Features and Indicators
10
7
3
2
5
4
1
11
9
8
6
12
