iSCSI and LAN Converged Storage Traffic
Topology
Fabric Inside Chassis: Converged iSCSI
Blade models: MXL or IOA
Top-of-Rack switch: S5000, S4810,
S4820T
Storage: iSCSI External Array
Configuration
Converged iSCSI traffic (LAN and
iSCSI) up to the Top-of-Rack switch
Topology / Configuration
Topology Diagram
VLT
LAG
LAG
Inside Chassis
iSCSI and LAN
from Adapter to
Blade switch
LAN
iSCSI & LAN
LAN
iSCSI
