Table 26. RAID Configuration for PowerEdge R510-12
Factory Configuration
No Mixed
HDD
(Must be all
2.5" or 3.5"
HDDs)
Type
#
Name
Description
Min
HDD
Max
HDD
No
HDD
40
NCZ
(recommende
d for hidden)
No Hard Drive (controller required, PERC H200, PERC H700)
0
0
No
RAID
(Add-
in
card)
41
ASS
No RAID (PERC H200)
1
12
RAID
(Add-
in
card)
42
ASSR0
RAID0 (PERC H200, PERC H700)
2
12
43
ASSR1
RAID1 (PERC H200, PERC H700)
2
2
44
ASSR10
RAID10 (PERC H200, PERC H700)
4
4
45
ASSR5
RAID5 (PERC H700)
3
12
46
ASSR6
RAID6 (PERC H700)
4
12
47
ASSR50
RAID50 (PERC H700)
6
12
48
ASSR60
RAID60 (PERC H700)
8
12
49
ASSR1/R1
RAID1+RAID1 (PERC H200, PERC H700)
2 + 2
2 + 2
50
ASSR1/R5
RAID1 + RAID5 (PERC H700)
2 + 3
2 +
10
51
ASSR5/R10
RAID5 + RAID10 (PERC H700)
4 + 4
4 + 8
R51012 Mixed HDD (SAS + SATA) Factory Configuration
Mixed SAS +
SATA
(Must be all
3.5" HDDs)
(ex. Min 2x
SAS + 2x
SATA;
Max 2x SAS
+ 6 SATA)
Type
#
Name
Description
Min
HDD
Max
HDD
Mix
HDD
(Add-
in
card)
52
ASS-X
No RAID (PERC H200)
2 + 2
2 +
10
