102 Configuring and Managing RAID
Physical Disks Disk Group # Properties:
• Number of virtuals disks (VD)
• Number of physical disks (PD)
• Space available on the physical disks
•Number of free segments
• Number of dedicated hot spares
Physical Disk # Physical Disk Properties:
•Vendor name
• Physical disk state
•Enclosure Position
• Slot Position
Disk Group # Properties:
• Number of virtuals disks (VD)
• Number of physical disks (PD)
• Space available on the physical disks
•Number of free segments
• Number of dedicated hot spares
Total Free Capacity Disk Group # Properties:
• Number of virtuals disks (VD)
• Number of physical disks (PD)
• Space available on the physical disks
•Number of free segments
• Number of dedicated hot spares
Table 6-3. Information on the Virtual Disk Management Screen (continued)
Menu Item Selected
in Left Panel
Information Displayed in Right Panel
