Cable cover for Dell Precision 3430 Small Form
Factor
The cable cover for a Dell Precision 3430 Small Form Factor helps protect ports and cables connected to the system.
Follow these steps to install the cable cover on the system chassis.
NOTE: Images shown below are for representation only and may vary depending on the system's conguration.
1 Slide the latch away from the chassis to unlock the cable cover.
2 Pull the tab on the cable release latch and lift the latch away from the cable cover.
3 Lift the tab [1], to release and pull the cable tie from the slot on the cable release latch [2].
1
4 Cable cover for Dell Precision 3430 Small Form Factor
