Dell Precision 7560 - Display

Table 19. Battery specifications (continued)
Description Option one Option two Option three
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
Display
The following table lists the display specifications of your Precision 7560.
Table 20. Display specifications
Description Option one Option two Option three Option four
Display type
15.6-inch Full High
Definition (FHD)
15.6-inch Full High
Definition (FHD)
15.6-inch Full High
Definition (FHD)
15.6-inch Ultra High
Definition (UHD)
Display-panel
technology
Wide-viewing angle
(WVA)
Wide-viewing angle
(WVA), WLED
Wide-viewing angle
(WVA), WLED
HDR600
Display-panel
dimensions (active
area):
Height
193.60 mm (7.62 in.) 193.59 mm (7.62 in.) 193.59 mm (7.62 in.) 193.59 mm (7.62 in.)
Width
344.20 mm (13.55 in.) 344.16 mm (13.55 in.) 344.16 mm (13.55 in.) 344.16 mm (13.55
in.)
Diagonal
394.90 mm (15.60 in.) 394.87 mm (15.60 in.) 394.87 mm (15.60 in.) 394.87 mm (15.60
in.)
Display-panel native
resolution
1920 x 1080 1920 x 1080 1920 x 1080 3840 x 2160
Luminance (typical)
220 nits 500 nits 500 nits 600 nits
Megapixels
2.07 2.07 2.07 8.29
Color gamut
45% NTSC 100% DCIP3 100% DCIP3 100% Adobe
Pixels Per Inch (PPI)
141 ppi 141 ppi 141 ppi 282
Contrast ratio (typ)
600:1 600:01 600:01 6000:1
Response time (min)
35 ms 35 ms 35 ms 35 ms
Refresh rate
60 Hz 60 Hz 60 Hz 60 Hz
Horizontal view angle
+/- 80 degrees(min) +/- 80 degrees(min) +/- 80 degrees(min) +/- 80 degrees(min)
Vertical view angle
+/- 80 degrees(min) +/- 80 degrees(min) +/- 80 degrees(min) +/- 80 degrees(min)
Pixel pitch
0.18 mm x 0.18 mm 0.18 x 0.18 mm 0.18 x 0.18 mm 0.090 x 0.090 mm
Power consumption
(maximum)
4.20 W 7.2 W 7.4 W 18 W
Anti-glare vs glossy
finish
Anti-glare Anti-glare Anti-glare Anti-glare
Touch options
No No Yes No
22 Specifications of Precision 7560
