Dell Precision T1600 User Manual

14
System Fan
Removing The System Fan
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Disconnect the chassis fan cable from the system board.
4. Pry and remove the system fan away from the four grommets securing it to the back
of the computer.
Related Links
Installing the System Fan
41

Dell Precision T1600 Specifications

General

Chipset	Intel C206
Optical Drive	DVD-ROM, DVD+/-RW
Processor Options	Intel Xeon E3-1200 series, Intel Core i3
Memory	Up to 16GB DDR3 (4 DIMM slots)
Storage Options	Up to 2TB SATA
Graphics Options	Intel HD Graphics, NVIDIA Quadro 600, NVIDIA Quadro 2000
Operating System Options	Windows 7 Professional, Linux
Power Supply	265W
Expansion Slots	1 PCIe x16, 1 PCIe x1, 1 PCI
Ports	1 RJ-45
