Dell Precision T3500 User Manual

Dell Precision™ T3500 Service Manual--Specifications
file:///C|/Biz%20Client/2015/NewBalance/Info%20Dev%20Root/New%20Balance/SM/A00/EN/Source/specs.htm[5/15/2015 11:40:57 AM]
Off (no light) . System is not connected to a
network
Back of the computer:
Link integrity light (on
integrated network
adapter)
Green . A good connection at 10Mbs exists
between the network and the computer.
Orange . A good connection at 100Mbs
exists between the network and the
computer.
Yellow . A good connection at 1000Mbs
exists between the network and the
computer.
Off . The computer is not detecting a
physical connection to the network.
Network activity light (on
integrated network
adapter)
Yellow blinking light
Power
DC power supply:
Wattage
525 W
Maximum heat dissipation
(MHD)
1194 BTU/hr
Voltage
115/230 VAC, 50/60 Hz, 6.0/3.0 A
Coin-cell battery 3 V CR2032 lithium coin cell
Physical
Height 44.8 cm (17.6 inches)
Width 17.2 cm (6.8 inches)
Depth 46.8 cm (18.4 inches)
Weight 17.3 kg (38.0 lb)
Environmental
Temperature range:
Operating 10° to 35°C (50° to 95°F)
Storage -40° to 65°C (-40° to 149°F)
Relative humidity (maximum): 20% to 80% (noncondensing)
Maximum vibration (using a random-
vibration spectrum that simulates user
environment):
Operating 5 to 350 Hz at 0.0002 G²/Hz
Storage 5 to 500 Hz at 0.001 to 0.01 G²/Hz
Maximum shock (measured with hard
drive in head-parked position and a 2-
ms half-sine pulse):

Dell Precision T3500 Specifications

General

Tcase	67.9 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	W3550
System bus rate	4.8 GT/s
Processor series	Intel Xeon 3500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Bloomfield
Processing Die size	263 mm²
Processor frequency	3.06 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.225 V
Number of processors installed	1
CPU multiplier (bus/core ratio)	23
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	24 GB
Display	LCD
Graphics card	FirePro V5900
Dimensions (WxDxH)	172 x 468 x 447 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card manufacturer	AMD
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® X58 Express
Memory slots	-
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	2 x 2 GB
HDD speed	7200 RPM
HDD capacity	500 GB
HDD interface	SATA III
Optical drive type	DVD Super Multi DL
Maximum graphics card memory	2.048 GB
Display diagonal	22 \
Display number of colors	16.78 million colors
PS/2 ports quantity	2
USB 2.0 ports quantity	11
VGA (D-Sub) ports quantity	0
Chassis type	Tower
Product color	Black, Silver
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Operating system installed	Windows XP Professional
Compatible operating systems	Windows 7
Power supply	525 W
Processor ARK ID	39720
Processor package size	42.5 x 45.0 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	468 mm
Width	172 mm
Height	447 mm
Weight	17700 g
