Monitor Specifications
Flat Panel Specifications
Screen type Active matrix - TFT LCD
Panel type In-plane switching technology
Screen dimensions 23 inches (23-inches viewable image size)
Preset display area: 533.2 (H) x 312.0 (V) mm
Horizontal 533.2 mm (20.99
inches)
Vertical 312.0 mm
(12.28 inches)
Pixel pitch 0.27 mm
Viewing angle
178 degree (vertical) typical
178 degree (horizontal) typical
Luminance output 270 cd/m²(typical)
Contrast ratio 1000 to 1 (typical), 8,000,000 : 1 (typical Dynamic Contrast On)
Faceplate coating Glare with hard-coating > 7H
Backlight LED edgelight system
Response Time 8 ms gray-to-gray (typical)
Color depth 16.7 million colors
Color Gamut 82%*
*[S2340T] color gamut (typical) is based on CIE1976 (82%) and CIE1931 (72%) test standards.
Resolutionn Specifications
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56
Hz
to 76 Hz (automatic)
Maximum preset resolution 1920 x 1080 at 60 Hz
Supported Video Modes
Video display capabilities 480p, 576p, 720p, 1080p, 480i, 576i, 1080i
