Dell S2340T Multi - Universal Serial Bus (USB) Interface

Universal Serial Bus (USB) Interface
This section gives you information about the USB ports that are available on the left side of your monitor.
NOTE: The USB ports on this monitor are USB 3.0 compliant.
Transfer speed Data
Rate
Power
Consumption
SuperSpeed 5 Gbps 4.5 W (Max., each port)
Hi-Speed 480 Mbps 2.5 W (Max., each port)
Full speed 12 Mbps 2.5 W (Max., each port)
Low speed 1.5 Mbps 2.5 W (Max., each port)
USB Upstream
Connector
USB Downstream
Connector
Pin Number Signal Name
1 VBUS
2 D-
3 D+
4 GND
5 StdB_SSTX-
6 StdB_SSTX+
7 GND_DRAIN
8 StdB_SSRX-
9 StdB_SSRX+
Shell Shield
Pin Number Signal Name
1 VBUS
2 D-
3 D+
4 GND
5 StdA_SSRX-
6 StdA_SSRX+
7 GND_DRAIN
8 StdA_SSTX-
9 StdA_SSTX+
Shell Shield
