Operating the Monitor
Dell™ S2340T Monitor User's Guide
Using the Side Panel Controls
Using the On-Screen Display (OSD) Menu
Setting the Maximum Resolution
USB Display, USB Audio, USB Ethernet set up
Using the Tilt and Touch Usage Scenario
Using the Side Panel Controls
Use the control buttons on the side of the monitor to adjust the characteristics of the image being displayed. As you use these buttons to adjust the controls, an OSD shows the
numeric values of the characteristics as they change.
The following table describes the side panel buttons:
Side Panel Button Description
1
Shortcut key/ Preset Modes
Use this button to choose from a list of preset color modes.
2
Shortcut key / Brightness/Contrast
Use this button to directly access the "Brightness/Contrast" menu.
3
Menu
Use the MENU button to launch the on-screen display (OSD) and select the OSD Menu. See Accessing the Menu System
.
