12 | About Your Monitor
Physical Characteristics
Connector type •HDMI connector
•Audio line-out
Signal cable type HDMI 1.8 M cable
Dimensions (with stand)
Height 411.6 mm (16.21 inches)
Width 537.5 mm (21.16 inches)
Depth 157.6 mm (6.20 inches)
Dimensions (without stand)
Height 312.8 mm (12.31 inches)
Width 537.5 mm (21.16 inches)
Depth 29.0 mm (1.14 inches)
Stand dimensions
Height
227.7 mm (8.96 inches)
Width 217.3 mm (8.55 inches)
Depth
157.6 mm (6.20 inches)
Weight
Weight with packaging 6.65 kg (14.66 lb)
Weight with stand assembly and
cables
4.00 kg (8.82 lb)
Environmental Characteristics
Temperature
Operating 0°C to 40°C (32°F to 104°F)
Non-operating –20°C to 60°C (–4°F to 140°F)
Humidity
Operating 20% to 80% (non-condensing)
Non-operating 10% to 90% (non-condensing)
Altitude
Operating 5,000 m (16,404 ft) (maximum)
Non-operating 12,192 m (40,000 ft) (maximum)
Thermal dissipation 112.59 BTU/hour (maximum)
68.24 BTU/hour (typical)
