About Your Monitor | 9
Monitor Specifications
Screen type Active matrix - TFT LCD
Panel Type Plane To Line Switching
Aspect ratio 16:9
Viewable image dimensions
Diagonal 60.45 cm (23.8 inches)
Active Area
Horizontal
527.04 mm (20.75 inches)
Vertical 296.46 mm (11.67 inches)
Area
156246.28 mm² (242.15 inches²)
Pixel pitch 0.2745 mm x 0.2745 mm
Pixel per inch (PPI) 93
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Brightness 400 cd/m² (typical)
600 cd/m² (peak)
Contrast ratio 1000 to 1 (typical)
8,000,000 to 1 (dynamic contrast on)
Faceplate coating Anti-glare treatment of the front polarizer (3H)
Backlight White LED, EDGELIGHT system
Response Time (Gray to Gray) 5 ms (FAST mode)
8 ms (NORMAL mode)
Color depth 16.7 million colors
Color gamut sRGB 1931 coverage 99% (typical)
DCI-P3 1976 coverage 85% (typical)
Connectivity •2 x HDMI2.0 with HDCP2.2(combine HDMI1.4 with
HDCP 1.4)
•1 x Analog 2.0 audio line out (3.5mm jack)
Border width (edge of monitor to
active area)
5.20 mm (Top)
5.20 mm (Left/Right)
7.70 mm (Bottom)
Adjustability
Tilt
Swivel
-5° to 21°
NA
Dell Display Manager (DDM)
Compatibility
Easy Arrange
and other key features
