Dell S3222HN Service Manual

4
No. Part No. Description Q’ty
1
Q23G315570001300DR LOGO DELL 22*7.37*0.18
1
2
Q34G97610VH01S0130 DECO_BEZEL L32WR-Edell1-p1
1
3
Q15G452220110100YX BEZEL_BTM
1
4
Q16G00036520000ADG SPONGE
1
5
Q34GA2950VHA1T0130 MIDDLE_FRAME L315WR-Edell1f-s1
1
6
Q33G16770VH01S0100 KEY
1
7
Q33G16760VH01S0100 KEY_POWER
1
8
Q15G449310150100YM MAINFRAME
1
9
Q33G20070VH01S0100 STAND_BUTTON
1
10
Q15G449510110100ZA BKT_HINGE
1
11
Q34G9760ASFB3S0130 REAR_COVER L315WR-Edell1f-s1
1
12
Q34GA296ASF01S0100 COVER_VESA L315WR-Edell1f-s1
1
13
Q23G315570001200DR LOGO DELL 60*60*0.24
1
14
Q52G1801J83P000ADG INSULATING SHEET 184*151.5*0.5mm
1
15
Q37G148610110100FH stand ass'y L315WR-Edell1f-s1 NA
1
E1
750GBV315110A1N0DL LCD TPM315WF1-HVR01.U FQ TPV
1
E2
KEPCPQE0 KEY BOARD
1
E3
CBPT1TMD0Q3 CONVERSION 715GC147M0B0000H400225
1
E4
PLPCLL301UQD1 POWER BOARD
1
E5
LNPCLL301UQD1 CONVERTER BOARD
1
S1
Q01G6019 1 SCREW
12
S2
QM1G38400601200ARA SCREW -- 6mm
1
S3
0D1G1030 6120 SCREW D3 6
10
S4
0M1G3030 4120 SCREW 3 4
19
S5
0M1G3030 4120 SCREW 3 4
1
S6
QM1G09300801200AWL SCREW M3 8
2
S7 0M1G2940 10125 SCREW M4 10 4

Dell S3222HN Specifications

General

Screen Size	31.5 inches
Resolution	1920 x 1080 (Full HD)
Panel Type	VA
Refresh Rate	75 Hz
Aspect Ratio	16:9
Brightness	300 cd/m²
Contrast Ratio	3000:1
Curvature	1800R
AMD FreeSync	Yes
Response Time	4 ms (GtG)
Ports	2 x HDMI 1.4
Viewing Angle	178° (horizontal), 178° (vertical)
Built-in Speakers	Yes (2 x 5W)
Color Support	16.7 million colors
VESA Mount	100 x 100 mm
