Dell S3222HN Service Manual

7
3.1 Disassembly Procedures:
Step Figure Remark
S1.Before
disassemble
Turn off power, Unplug
external cables from
product
S2.Remove the
STAND-BASE
ASS’Y
Lay down the MNT on a
curve cushion.
Use a screw to press the
button to remove the
stand-base a’ssy.

Dell S3222HN Specifications

General

Screen Size	31.5 inches
Resolution	1920 x 1080 (Full HD)
Panel Type	VA
Refresh Rate	75 Hz
Aspect Ratio	16:9
Brightness	300 cd/m²
Contrast Ratio	3000:1
Curvature	1800R
AMD FreeSync	Yes
Response Time	4 ms (GtG)
Ports	2 x HDMI 1.4
Viewing Angle	178° (horizontal), 178° (vertical)
Built-in Speakers	Yes (2 x 5W)
Color Support	16.7 million colors
VESA Mount	100 x 100 mm
