Dell S3222HN Service Manual

9
Use Penknife to seperate
the rear cove follow the
arrows in sequence, then
you can take out rear
cover.
S4.Tear off the
tapes and
disconnect the
connectors
Tear off 4 pieces of
aluminum foil and 2
pieces of tapes.
Disconnect the pins.
3
1
1
2
2
3
4
4

Dell S3222HN Specifications

General

Screen Size	31.5 inches
Resolution	1920 x 1080 (Full HD)
Panel Type	VA
Refresh Rate	75 Hz
Aspect Ratio	16:9
Brightness	300 cd/m²
Contrast Ratio	3000:1
Curvature	1800R
AMD FreeSync	Yes
Response Time	4 ms (GtG)
Ports	2 x HDMI 1.4
Viewing Angle	178° (horizontal), 178° (vertical)
Built-in Speakers	Yes (2 x 5W)
Color Support	16.7 million colors
VESA Mount	100 x 100 mm
