Figure 16. Rear View of the Enclosure Showing the Failed Cooling Fan Module
Replacing a Cooling Fan Module
Use this procedure to replace a failed cooling fan module.
Prerequisites
Use SupportAssist to send diagnostic data to Dell Technical Support.
About this task
You can replace cooling fan modules one at a time without shutting down the storage system.
Steps
1. Press the release tab and pull the cooling fan module out of the chassis using the handle.
CAUTION: The fan modules are heavy. To avoid injury, use both hands while removing the
module.
Replacing SCv2080 Storage System Components
27
