Dell SP2208W FP - Back View


Back View


Front View
Front panel controls
1
VGA LED
2
DVI LED
3
HDMI LED
4
Video input select
5
OSD menu / select button
6
Brightness & Contrast / Down (-) button
7
Auto-Adjust / Up (+) button
8
Power button (with power light indicator)
9
Webcam
10
MIC
Back view
Back view with monitor stand
1
VESA mounting holes (100mm) (Behind
attached base plate)
Use to mount the monitor.
2
Barcode serial number label
Refer to this label if you need to contact Dell for technical support.
3
Security lock slot
Use a security lock with the slot to help secure your monitor.
4
Dell Soundbar mounting brackets
Attach the optional Dell Soundbar.
5
Regulatory rating label
List the regulatory approvals.
6
Stand removal button
Press to release the stand.
7
Cable management hole
Help organize cables by placing them through the hole.
