Dell ST2220 - Flat Panel Specifications; Video Supported Modes


Flat Panel Specifications
* Based on estimation
** ST2220 Color Gamut (Typical) is based on CIE1976 (78 %) and CIE1931 (68 %).
Resolution

Video Supported Modes

7
GND-G
8
GND-B
9
Computer 5V/3.3V
10
GND-sync
11
GND
12
DDC data
13
H-sync
14
V-sync
15
DDC clock
Model
ST2220
Screen type
Active matrix - TFT LCD
Panel type
TN
Screen dimensions
54.61cm (21.5 inches) (21.5-inch viewable image size)
Preset display area: Horizontal
Vertical
476.64 mm (18.76 inches)
268.11 mm (10.56 inches)
Pixel pitch
0.248 mm
Viewing angle
160°(vertical)typical,170°(horizontal)typical
Luminance output
250 CD/m ²(typical)
Contrast ratio
1000:1 (typical)
Dynamic Contrast Ratio
8,000,000 to 1*
Faceplate coating
Antiglare with hard-coating 3H
Backlight
LED light bar system
Response Time
5 ms typical
Color Depth
16.7 mil colors
Color Gamut
78 %**
Model
ST2220
Horizontal scan range
30 kHz to 83 kHz (automatic)
Vertical scan range
56Hzto76Hz(automatic)
Maximum preset resolution
1920 x 1080 at 60 Hz
Model
ST2220
Video display capabilities (HDMI playback)
480i/480p/576i/576p/720p/1080i/1080p
