Dell U2412M - Monitor Specifications

Monitor Specifications
Flat Panel Specifications
*[U2412M] color gamut (typical) is based on CIE1976 (82%) and CIE1931 (72%) test standards.
Resolution Specifications
Supported Video Modes
Preset Display Modes
U2412M
Model
U2412M
Screen type
Active matrix - TFT LCD
Panel type
IPS
Screen dimensions
60.96 cm (24-inches viewable image size)
Preset display area
518.4 (H) X 324.0 (V) mm
Horizontal
518.4 mm (20.3 inches)
Vertical
324.0 mm (12.7 inches)
Pixel pitch
0.27 mm
Viewing angle
178°(vertical)typical
178°(horizontal)typical
Luminance output
300 cd/m²(typical)
Contrast ratio
1000 to 1 (typical), 2M to 1 (typical Dynamic Contrast On)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
LED edgelight system
Response time
8 ms gray-to-gray (typical)
Color depth
16.7 million colors
Color gamut
82%*
Model
U2412M
Horizontal scan range
30 kHz to 83 kHz (automatic)
Vertical scan range
50Hzto61Hz(automatic)
Maximum preset resolution
1920 x 1200 at 60 Hz
Model
U2412M
Video display capabilities (DVI & DP playback)
480p, 576p, 720p, 1080p,
576i, 1080i
Display Mode
Horizontal Frequency
(kHz)
Vertical Frequency (Hz)
Pixel Clock (MHz)
Sync Polarity (Horizontal/Vertical)
VESA, 720 x 400
31.5
70.0
28.3
-/+
VESA, 640 x 480
31.5
59.9
25.2
-/-
VESA, 800 x 600
37.9
60.3
40.0
+/+
VESA, 1024 x 768
48.4
60.0
65.0
-/-
VESA, 1280 x 1024
64.0
60.0
108.0
+/+
VESA, 1600 x 1200
75.0
60.0
162.0
+/+
