Dell U2412M - Electrical Specifications; Physical Characteristics; Environmental Characteristics

Electrical Specifications
Physical Characteristics
Environmental Characteristics
VESA, 1680 x 1050
64.7
59.9
119.0
+/-
VESA, 1920 x 1080
66.6
59.9
138.5
+/-
VESA, 1920 x 1200
74.0
60.0
154.0
-/+
Model
U2412M
Video input signals
Analog RGB, 0.7 Volts +/- 5%, positive polarity at 75 ohm input
impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at
50 ohm input impedance
DP 1.1a signal input support
Synchronization input signals
TTL levels required and separate syncs (including Trigger points), SOG
(Composite SYNC on green)
AC input
voltage/frequency/current
100 to 240 VAC / 50 or 60 Hz + 3 Hz / 1.2 A (typical)
Inrush current
120 V : 30 A (Max)
240 V : 60 A (Max)
Model
U2412M
Connector type
15-pin D-subminiature, blue connector; DVI-D, white
connector; DP, black connector.
Signal cable type
Digital: detachable, DVI-D, solid pins, shipped detached from the monitor
Analog: attachable, D-Sub, 15pins, shipped detached from the monitor
Dimensions (with stand)
Height (extended)
513.5 mm (20.22 inches)
Height (compressed)
398.5 mm (15.69 inches)
Width
556.0 mm (21.89 inches)
Depth
180.3 mm (7.10 inches)
Dimensions (without stand)
Height
361.6 mm (14.24 inches)
Width
556.0 mm (21.89 inches)
Depth
64.9 mm (2.56 inches)
Stand dimensions
Height (extended)
400.7 mm (15.78 inches)
Height (compressed)
285.7 mm (11.25 inches)
Width
279.8 mm (11.02 inches)
Depth
180.3 mm (7.10 inches)
Weight
Weight with packaging
16.48 lbs (7.49 kg)
Weight with stand assembly and cables
13.73 lbs (6.24 kg)
Weight without stand assembly
(For wall mount or VESA mount considerations -
no cables)
8.73 lbs (3.97 kg)
Weight of stand assembly
3.87 lbs (1.76 kg)
Front frame gloss
5.0 gloss unit (max.) (Black Frame)
20.0 gloss unit (max.) (Silver Frame)
Model
U2412M
Temperature
Operating
0°Cto40°C
