Dell vostro 15-3565 User Manual

Installing the coin cell battery
1. Insert the coin cell battery into the battery slot.
2. Press the battery until it clicks into place.
3. Install the:
a. base cover
b. keyboard
c. optical drive
d. battery
4. Follow the procedures in After working inside your computer.
Removing the WLAN card
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. battery
b. optical drive
c. keyboard
d. base cover
3. To remove the WLAN card:
a. Disconnect the WLAN cables from the connectors on the WLAN card [1].
b. Remove the secure that secures the WLAN card to the system board [2].
c. Remove the WLAN card from the computer [3].
22

Dell vostro 15-3565 Specifications

General

RAM	4GB DDR4
Display	15.6-inch HD (1366 x 768)
Operating System	Windows 10 Home
Optical Drive	DVD-RW
Graphics	AMD Radeon R5
Battery	4-cell 40Whr
Weight	2.18 kg
Ports	2 x USB 3.0, 1 x USB 2.0, HDMI, SD card reader
Storage	Up to 1TB 5400 RPM HDD
