Steps
1. Align the power button with fingerprint reader on the palm-rest and keyboard assembly.
2. Connect the power button with fingerprint reader cable to the connector on the palm-rest and keyboard assembly.
3. Adhere the mylar tape that secures the power button with fingerprint reader cable connection.
Next steps
1. Install the power button with fingerprint reader.
2. Install the power-adapter port.
3. Install the display assembly.
4. Install the system board.
5. Install the speakers.
6. Install the wireless card.
7. Install the 4-cell battery.
8. Install the 3-cell battery.
9. Install the base cover.
10. Follow the procedure in After working inside your computer.
46
Removing and installing components
