Table 15. Power adapter specifications(continued)
Description Option one Option two
Depth
25.4 mm (1 in.) 30 mm (1.18 in.)
Input voltage
100 VAC240 VAC 100 VAC240 VAC
Input frequency
50 Hz60 Hz 50 Hz60 Hz
Input current (maximum)
2.50 A 2.34 A
Output current (continuous)
6.70 A 9.23 A
Rated output voltage
19.50 VDC 19.50 VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) C to 40°C (32°F to 104°F)
Storage
-40°C to 70°C (-40°F to 158°F) -40°C to 70°C (-40°F to 158°F)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
Power-supply unit
NOTE: The power rating specification is only applicable to computers shipped with High Performance processors.
Table 16. Power rating
Description Values
Type
160 W internal power supply unit (PSU), 80 Plus Bronze
Input voltage
90 VAC264 VAC
Input frequency
47 Hz63 Hz
Input current (maximum)
2.80 A
Output current (continuous)
Operating:
19.50 VA: 7 A
19.50 VB: 5 A
Standby:
19.50 VA: 0.50 A
19.50 VB: 1.75 A
Rated output voltage
19.50 VA
19.50 VB
Temperature range:
Operating
5°C to 42°C (41°F to 107.6°F)
Storage
-40°C to 70°C (-40°F to 158°F)
Specifications of OptiPlex All-in-One 7410 29
