Table 24. Screw list for computers with Energy Efficient Processors(continued)
Component Screw type Quantity
Hard drive M3x3.5 4
M.2 2230/2280 solid-state drive M2x3.5 1
I/O cover M3x5 2
Bottom cover M3x5 3
Retractable-camera assembly M3x5 4
Fan M3x5 3
I/O bracket M3x5 3
Heat sink Captive 5
System board M3x5 7
M3x12 1
Power-button and I/O board shield M3x5 3
Power-button and I/O board M3x5 2
Audio board shield M3x5 3
Audio board M3x5 2
Major components of OptiPlex All-in-One 7410
The following image shows the major components of OptiPlex All-in-One 7410.
NOTE: This is the major components for computers shipped with a High Performance processor.
38 Working inside your computer
