Dell E173FPc
5
1. Monitor Specifications
Driving system TFT Color LCD
LPL：LM170E01 TLB4
Hydis：HT17E13-100
Panel type
CPT: CLAA170EA 07
Size 43.27cm (17.0")
Pixel pitch 0.264mm(H) x 0.264mm(V)
LPL Panel：140˚ (H) 140˚ (V)
Hydis panel：150˚ (H) 140˚ (V)
Viewable angle
CPT panel：140˚ (H) 130˚ (V)
LPL Panel：8 ms
LCD Panel
Response time (typ.)
Hydis & CPT panel：12 ms
Video Analog Only
Sync. Type H/V TTL Separate and Composite Sync.
H-Frequency 30kHz – 80kHz
Input
V-Frequency 56 - 75Hz
Display Colors 16.2 M
Dot Clock 135MHz (max.)
Max. Resolution 1280 x 1024
Plug & Play VESA DDC2B
On Mode <35W
Power Consumption
Power Saving <2W
Maximum Screen Size
Horizontal: 358.5mm
Vertical: 296.5mm
Power Source 90~264VAC, 47~63Hz
Temp.: 5°C to 40°C
Operating
Humidity: 10% to 80%
Temp.: -20°C to +60°C
Environmental Considerations
Storage/shipping
Humidity: 5% to 90%
Packaged 5.8Kgs Unit
Weight (N. W.)
Unpackaged 4.6Kgs Unit
