Dell XPS 13 9340 - XPS 13 9340 Component Views; Right Side View; Left Side View

Views of XPS 13 9340
Right
Figure 1. Right view
1. Thunderbolt 4 port with Power Delivery (Type-C)
Supports USB4, DisplayPort 1.4, Thunderbolt 4 and also enables you to connect to an external display using a display adapter.
Provides data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4.
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
NOTE: USB4 is backward compatible with USB 3.2, USB 2.0, and Thunderbolt 3.
NOTE: Thunderbolt 4 supports four 4K displays, one 5K display, or one 8K display.
Left
Figure 2. Left view
1. Thunderbolt 4 port with Power Delivery (Type-C)
Supports USB4, DisplayPort 1.4, Thunderbolt 4 and also enables you to connect to an external display using a display adapter.
Provides data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4.
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
NOTE: USB4 is backward compatible with USB 3.2, USB 2.0, and Thunderbolt 3.
NOTE: Thunderbolt 4 supports four 4K displays, one 5K display, or one 8K display.
1
6 Views of XPS 13 9340
